LM12-2002A , Proximity Sensor , Proximity Switch
Kategori
Stok Kodu
RF-2.7
193,59 TL + KDV
232,31 TL
Kalan Stok : 10
LM12-2002A , Proximity Sensor , Proximity Switch
copper shell; 2, Cable length2 metres , Ip65
Sensor Tipi: Endüktif, Düz Kafa Sensor Çapı: 12mm Gövde şekli: Silindirik, Metal, Algılama Mesafesi: 2mm Çalışma Voltajı: 90-220V AC Çıkış: NPN NO 2m 3 kablolu
| Detect distance |
2mm | ||||
| NO | LM12-3002NA | ||||
| NPN | NC | LM12-3002NB | |||
| NO+NC | LM12-3002NC | ||||
| DC | PNP | NO | LM12-3002PA | ||
| Flush | 6-36VDC | NC | LM12-3002PB | ||
| Type | NO+NC | LM12-3002PC | |||
| Two wire | NO | LM12-3002LA | |||
| system | NC | LM12-3002LB | |||
| AC | Control Silicon | NO | LM12-2002A | ||
| 90-250VAC | NC | LM12-2002B | |||
| NO+NC | |||||
| AC | Relay Output | ||||
| Detect distance | 4MM | ||||
| NO | LM12-3004NA | ||||
| DC | NPN | NC | LM12-3004NB | ||
| NO+NC | LM12-3004NC | ||||
| DC | NO | LM12-3004PA | |||
| Non- | 6-36VDC | PNP | NC | LM12-3004PB | |
| Flush | NO+NC | LM12-3004PC | |||
| Type | DC | Two wire | NO | LM12-3004LA | |
| AC | system | NC | LM12-3004LB | ||
| AC 90-250VAC | control silicon | NO | LM12-2004A | ||
| NC | LM12-2004B | ||||
| NO+NC | |||||
| Relay Output | |||||
| Ouput current | DC | 200mA | |||
| Relay output | 300mA | ||||
| Output voltage drop | DC/AC below 3V/ 10V | two wire below 3.9V | |||
| Consumption current | DC below 15mA | AC Below10mA | |||
| Detect object | 15 x 15 x 1 A3 iron | ||||
| Repeated precision | 0.01 | ||||
| Response frequency | DC/AC | 400Hz /25Hz | |||
| Ambient Temperature | -25℃~ +75℃ | ||||
| Shell material | Metal | ||||
| Protection grade | IP67 | ||||
