AD7523JN , AD7523 DIP , 8-Bit, Multiplying D/A Converters
Features

• 8-Bit, 9-Bit and 10-Bit Linearity

• Low Gain and Linearity Temperature Coefficients

• Full Temperature Range Operation

• Static Discharge Input Protection

• TTL/CMOS Compatible

• Supply Range . . . . . . . . . . . . . . . . . . . . . . . . +5V to +15V

• Fast Settling Time at 25

o

C . . . . . . . . . . . . 150ns (Max)

• Four Quadrant Multiplication

• AD7533 Direct AD7520 Equivalent

Description

The AD7523 and AD7533 are monolithic, low cost, high

performance, 8-bit and 10-bit accurate, multiplying digital-to-

analog converter (DAC), in a 16 pin DIP.

Intersil’ thin film resistors on CMOS circuitry provide 10-bit

resolution (8-bit, 9-bit and 10-bit accuracy), with TTL/CMOS

compatible operation.

The AD7523 and AD7533s accurate four quadrant

multiplication, full military temperature range operation, full

input protection from damage due to static discharge by

clamps to V+ and GND, and very low power dissipation

make it a very versatile converter.

Low noise audio gain controls, motor speed controls,

digitally controlled gain and digital attenuators are a few of

the wide range of applications of the AD7523 and AD7533.

Ordering Information

PART NUMBER

LINEARITY (INL, DNL)

TEMP. RANGE (

o

C)

PACKAGE

PKG. NO.

AD7523JN, AD7533JN

0.2% (8-Bit)

0 to 70

16 Ld PDIP

E16.3

AD7523KN, AD7533KN

0.1% (9-Bit)

0 to 70

16 Ld PDIP

E16.3

AD7523LN, AD7533LN

0.05% (10-Bit)

0 to 70

16 Ld PDIP

E16.3

Pinout

AD7523, AD7533

(PDIP)

TOP VIEW

NOTE:

1. NC for AD7523 only.

Functional Block Diagram

NOTE: Switches shown for digital inputs “High”

I

OUT1

I

OUT2

GND

BIT 1 (MSB)

BIT 2

BIT 3

BIT 5

BIT 4

R

FEEDBACK

V+

NC/BIT 10

NC/BIT 9

BIT 8

BIT 7

BIT 6

V

REF IN

(NOTE 1)

(NOTE 1)

MSB

(4)

20k

Ω

(3)

BIT 3

BIT 2

V

REF IN

20k

Ω

20k

Ω

20k

Ω

20k

Ω

20k

Ω

10k

Ω

10k

Ω

10k

Ω

10k

Ω

SPDT

NMOS

10k

Ω

I

OUT2

(2)

I

OUT1

(1)

R

FEEDBACK

(15)

SWITCHES

(16)

(5)

(6)

File Number

3105.1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

http://www.intersil.com or 407-727-9207

|

Copyright

©

Intersil Corporation 1999
