LM8-3001NA , Proximity Sensor , Proximity Switch
Kategori
Stok Kodu
RF-1.2
193,59 TL + KDV
232,31 TL
Kalan Stok : 10
LM8-3001NA , Proximity Sensor , Proximity Switch
copper shell; 2, Cable length2 metres , Ip65
Sensor Tipi: Endüktif, Düz Kafa Sensor Çapı: 8mm Gövde şekli: Silindirik, Metal, Algılama Mesafesi: 1mm Çalışma Voltajı: 10-30V DC Çıkış: NPN NO 2m 3 kablolu
| Detect distance |
1mm | ||||
| NO | LM8-3001NA | ||||
| NPN | NC | LM8-3001NB | |||
| NO+NC | |||||
| DC | PNP | NO | LM8-3001PA | ||
| Flush | 6-36VDC | NC | LM8-3001PB | ||
| Type | NO+NC | ||||
| Two wire | NO | LM8-3001LA | |||
| system | NC | LM8-3001LB | |||
| AC | Control Silicon | NO | |||
| 90-250VAC | NC | ||||
| NO+NC | |||||
| AC | Relay Output | ||||
| Detect distance | 2MM | ||||
| NO | LM8-3002NA | ||||
| DC | NPN | NC | LM8-3002NB | ||
| NO+NC | |||||
| DC | NO | LM8-3002PA | |||
| Non- | 6-36VDC | PNP | NC | LM8-3002PB | |
| Flush | NO+NC | ||||
| Type | DC | Two wire | NO | LM8-3002LA | |
| AC | system | NC | LM8-3002LB | ||
| AC 90-250VAC | control silicon | NO | |||
| NC | |||||
| NO+NC | |||||
| Relay Output | |||||
| Ouput current | DC | 150mA | |||
| Output voltage drop | NPN/PNP below 3V | two wire below 3.9V | |||
| Consumption current | DC below 15mA | AC Below10mA | |||
| Detect object | 8 x 8 x 1 A3 iron | ||||
| Repeated precision | 0.01 | ||||
| Response frequency | DC/AC | 500Hz /25Hz | |||
| Ambient Temperature | -25℃~ +75℃ | ||||
| Shell material | Metal | ||||
| Protection grade | IP67 | ||||
